線束加工常見名稱中英文對照表
- 作者: 深華
- 來源: 纜仕特電子
- 日期 : 2024-04-07
在線束加工行業中，我們難免會接觸到很多外資企業，他們的技術圖紙或文檔說明一般常見的一些名稱都是英文描述，掌握一些基本的英文名稱是很有必要的，下面給大家總結了一份《線束加工常見名稱中英文對照表》。
| Raw material | 原材料 |
| Cover | 蓋子 |
| Nut | 螺母 |
| Washer | 墊圈 |
| TPA/PLR | 鎖止片 |
| Channel | 通道 |
| Fuse box | 保險盒 |
| Fuse | 保險 |
| Heat shrink tube | 熱縮管 |
| Plug | 堵頭 |
| Clip | 定位夾 |
| Strap | 扎帶 |
| Wire | 電線 |
| Harness | 線束 |
| Sub Assy Wiring Harness | 半成品線 |
| Cable | 電纜 |
| Battery Cable | 電瓶線 |
| Bracket | 支架 |
| Corrugated Tube | 波紋管 |
| PVC Tube | PVC 管 |
| Tube | 管件 |
| ELECTRONICAL COMPONENT | 電子零件 |
| Junction Box | 接線盒 |
| Grommet | 護套 |
| Tape | 膠帶 |
| Plastic | 塑料件 |
| Relay | 繼電器 |
| Rubber | 橡膠件 |
| Seal | 密封塞 |
| Terminal | 端子 |
| Male Terminal | 公端子 |
| Female Terminal | 母端子 |
| Eyelet | 環端 |
| Fiber | 光纖 |
| Mat Seal | 密封墊 |
| Blind Cavity | 盲孔 |
| Cavity | 孔位 |
| Cavity No. | 孔位號 |
| Sleeve | 袖套 |
| PET Tape | PET 膠帶 |
| Foam Tape | 泡沫膠帶 |
| PVC Tape | PVC 膠帶 |
| Textile Tape | 無紡布膠帶 |
| Felt Tape | 毛氈膠帶 |
| Glass Cloth Tape | 玻璃布膠帶 |
| Connector | 連接器 |
| Conductor | 導體 |
| Waterproof | 防水 |
| Pusher | 推桿 |
| Diameter | 直徑 |
| PUR Tube | PUR 管 |
| Gold Plated Terminal | 鍍金端子 |
| Tin Plated Terminal | 鍍錫端子 |
| Silver Plated Terminal | 鍍銀端子 |
| Multicore Wire | 多芯線 |
| Screening Wire | 屏蔽線 |
| Diode | 二極管 |
| 操作名稱 | |
| Spot Tape | 點纏 |
| Full Tape | 全纏 |
| Spiral Tape | 間距纏 |
| Crossing Tape | 交叉纏 |
| Terminal Insert | 插端子 |
| Rework | 返工 |
| E-test | 電測 |
| Pre-assembly | 預裝 |
| Tape Wound | 纏帶 |
| Quality Inspection | 質檢 |
| Process Check | 過程檢查 |
| First Piece Inspection | 首檢 |
| Last Piece Inspection | 末檢 |
| Splice | 鉸接 |
| Twist | 絞線 |
| Crimp | 壓接 |
| Tube Heating | 烘管 |
| Assembly | 裝配 |
| Wire Cutting | 切線 |
| Strip | 剝皮 |
| Weld | 焊接 |
| Ultrasonic | 超聲波 |
| Ultrasonic Weld | 超聲波焊接 |
| Tape Back | 回纏 |
| Package | 包裝 |
| Scan | 掃描 |
| Torque | 扭矩 |
| Maintenance | 維修 |
| 線束名稱 | |
| Rear Door Harness | 后門線束 |
| Front Door Harness | 前門線束 |
| Wheelhouse Harness | 機艙線束 |
| Body Harness | 車身線束 |
| Engine Harness | 發動機線束 |
| Roof Harness | 頂棚線束 |
| Epas Harness | 電動助力轉向線束 |
| Front bumper Harness | 前保險杠線束 |
| Rear bumper Harness | 后保險杠線束 |
| Tailgate R Harness | 右尾門線束 |
| Tailgate L Harness | 左尾門線束 |
| Engine Ground Harness | 發動機接地線 |
| Underbody Harness | 底板線束 |
| IP Harness/ Instrument Panel Harness | 儀表板線束 |
| Starter Alternator | 啟動發電機線束 |
| Main Battery Ground | 主蓄電池接地線 |
| Front Door Ground Illumination | 前門接地照明線束 |
| Rear Door Ground Illumination | 后門接地照明線束 |
| Rear Door Handle Adapter Harness | 后門把手轉換線束 |
| 工裝設備工具 | |
| Assembly board | 工裝板/裝配板 |
| Fork（tooling fork） | 工裝叉 |
| OLTT(off line test table) | 電測臺 |
| Inspection Table | 全檢臺/檢測臺 |
| Packaging Table | 包裝臺 |
| Scan Table | 掃描臺 |
| Clip Board | 定位夾板/卡扣板 |
| Clip Fixture | 定位夾夾具/卡扣夾具 |
| Grommet Fixture | 護套夾具 |
| Connector Fixture | 連接器夾具 |
| Visual Aid | 目視輔助 |
| Rework Screwdriver | 返工/返工起子 |
| Strap Gun | 扎帶槍 |
| Tube Assembling Tool/Tube insertion tool | 上管器 |
| Tube Cutter | 切管機 |
| Diagonal Pliers | 斜口鉗 |
| Layout | 布局圖 |
| Scanner(looks like gun) | 掃描槍 |
| Pressure guage | 壓力檢具 |
| (Push tool) | 推工具 |
| detection pin | 探針 |
| Module | 模塊 |
| Wire Cutter | 切線機 |
| Ultrasonic Welding Machine | 超聲波焊接機 |
| Tube Heating Machine | 烘管機 |
| Stripper | 剝皮機 |
| Torque wrench | 扭力扳手 |
| 成品以及半成品 | |
| Branch | 分支 |
| Bundle | 捆，束 |
| Node | 節點 |
| Trunk | 主干 |
| Tolerance | 公差 |
| Orientation | 方向 |
| Fixture | 夾具 |
| Label | 標簽 |
| Bar Code | 條形碼 |
| Two-dimension Code | 二維碼 |
| Error Proofing | 防差 |
| Sample | 樣件 |
| Master Sample | 標準樣件 |
| Product Sample | 產品樣件 |
| Warehouse | 倉庫 |
| Dimension | 尺寸 |
| Deviation | 偏差 |
| Bellmouth | 喇叭口 |
| Copper Strand | 銅絲 |
| Plate | 鍍層 |
| Splice | 鉸接點 |
| Twisted Circuit | 麻花線 |
| Twist Pitch | 絞距 |
| Parameter | 參數 |
| Compressing Rate | 壓縮比 |
| Special Characteristics/SC | 特殊特性 |
| Critical Characteristics/CC | 重要特性 |
| Front Bellmouth | 前喇叭口 |
| Rear Bellmouth | 后喇叭口 |
| Window | 窗口/窗戶 |
| Cut Off Tabs | 切斷尾料 |
| Cross-Section | 橫截面 |
| Strip Length | 剝皮長度 |
| Pull Force | 拉力 |
| Conductor | 導體 |
| Conductor Wing | 導體壓接翼 |
| Conductor Crimp | 線芯壓接 |
| Conductor Crimp Width/CCW | 線芯壓接寬度 |
| Conductor Crimp Height/CCH | 線芯壓接高度 |
| Insulation | 絕緣層 |
| Insulation Wing | 絕緣（層）壓接翼 |
| Insulation Crimp | 絕緣層壓接 |
| Insulation Crimp Width/ICW | 絕緣層壓接寬度 |
| Insulation Crimp Height/ICH | 絕緣層壓接高度 |
| 不良描述 | |
| Fracture | 斷股 |
| low pull Force | 低拉力 |
| Scratch | 劃傷-injury |
| Burnt | 燒傷 |
| Over Weld | 過燒 |
| Raw weld | 漏壓 |
| Deform | 變形 |
| Oxidize | 氧化 |
| Discoloration | 退色/變色 |
| Cross Wires | 線交叉 |
| Open Circuit | 開路 |
| Short Circuit | 短路 |
| Rotate | 旋轉 |
| Clip Rotate | 定位夾旋轉 |
| Wild Strand | 散絲 |
| Missing Wires | 支路遺漏/漏線 |
| Damaged Wires | 支路破損 |
| Wrong Wires | 支路錯誤 |
| Cross Wire | 支路交叉 |
| Wrong Branch Dimension | 分支尺寸錯誤 |
| Wrong Branch Orientation | 分支方向錯誤 |
| Tight Circuit | 單根受力 |
| Wrong Branch | 分支錯誤 |
| Unseated Terminal | 端子未到位 |
| Damaged/Broken Terminal | 端子損壞/變形 |
| Faulty Terminal Crimping | 端子壓接不良 |
| Missing Terminal | 端子缺失/遺漏 |
| Wrong Terminal | 端子用錯/錯誤 |
| Unseated cover | 蓋子未到位 |
| Wrong Connector | 連接器用錯 |
| Damaged Connector | 連接器損壞 |
| Missing Connector | 連接器缺失/遺漏 |
| Damged TPA | 鎖止片損壞 |
| Missing TPA | 鎖止片遺漏 |
| Unseated TPA | 鎖止片未到位 |
| Foreign Material in Connector | 連接器有異物 |
| Missing Seals/Plugs | 密封塞/堵頭缺失/遺漏 |
| Wrong Seals/Plugs | 密封塞/堵頭用錯/錯誤 |
| Wrong Slide | 滑片用錯/錯誤 |
| Pressed Terminal | 端子插入過度 |
| Wrong Terminal insertion orientation | 端子插入方向錯誤 |
| Wrong Ring-terminal assembly sequence | 環端組裝順序錯誤 |
| Missing Clip/Strap | 定位夾/扎帶遺漏 |
| Wrong Clip/Strap Orientation | 定位夾/扎帶方向錯誤 |
| Wrong Clip/Strap | 定位夾/扎帶錯誤 |
| Wrong Clip Dimension | 定位夾尺寸錯誤 |
| Damged Clip/Strap | 定位夾/扎帶損壞/壞了 |
| Wrong Tape | 膠帶用錯 |
| Tape Wound Defect | 膠帶纏繞不良 |
| Missing Tape | 膠帶遺漏 |
| Wrong Cross-wound tape | 膠帶回纏錯誤 |
| Missing Cross-wound tape | 膠帶回纏遺漏 |
| Damged Tape | 膠帶損壞/壞了 |
| Wrong Channel/Bracket | 通道、支架用錯 |
| Missing Channel/Bracket | 通道、支架遺漏 |
| Damged Channel/Bracket | 通道、支架損壞 |
| Wrong Channel Assembly | 通道安裝/組裝錯誤 |
| Wrong Grommet | 護套用錯 |
| Missing Grommet | 護套遺漏 |
| Damaged Grommet | 護套損壞 |
| Wrong Grommet Assembly | 護套組裝錯誤 |
| Wrong Tube | 管子用錯 |
| Missing Tube | 管子遺漏 |
| Damaged Tube | 管子損壞 |
| Wrong Tube Assembly | 管件安裝/組裝錯誤 |
| Missing testing label | 電測/測試標簽遺漏 |
| Wrong testing label | 電測標簽錯誤 |
| Missing Label | 標簽遺漏 |
| Missing Packaging | 包裝遺漏 |
| Defective Splicing/Splicing Joint | 鉸接點脫落 |
| Wrong Splicing Joint | 鉸接點錯誤 |
| Faulty Welding | 焊接不良 |
| Missing Raw Material | 原材料遺漏 |
| Defective Raw Material | 原材料不良 |
| Unfasten Clip | 卡扣/定位夾扣合不良/松開 |
| Damged Fuse Box | 保險盒損壞 |
| Missing Fuse | 保險絲缺件 |
| Damged Fuse | 保險絲損壞 |
| Wrong Fuse | 保險絲用錯 |
